PP80 - Push-Pull Quick-release Couplings

Information request

Description

Features:



  • These quick couplings are interchangeable according to ISO 7241-1 part A standard
  • Shut-off poppet valve system for PV80 and ball system for PS80
  • Machined from high tensilesteel and carbonitrited / induction hardened for wear parts, they are zinc plated with a yellow chromate finish
  • Standard seal materials are Nitrile Rubber (NBR). On request: Viton, EPDM, Neoprene (CR) or other seals
  • Back up rings in PTFE
  • Working temperatures with standard seals (NBR) from -25°C to +125°C
  • Connectability without pressure
  • Disconnection under pressure is not allowed
  • On request, size 1/2" is available with connectability in presence of residual pressure
  • PVC, Nylon and Aluminium protective dust plug and caps are available



Technical Data:

Applications:

This coupling is manufactured a good choice of agricultural applications. Thanks to its double effect sleeve, it is very easy to connect and to disconnect in a little space.

Dimensions:

* Metric, NPTF and UNF threads are available on request
