W60sb - six-ways steel body diverter valves

Description

USE AND OPERATION:

This valve is used to divert the flow from 2 ways in towards 4 ports (2 at time alternatively). It's ideal to control 2 actuators.

MATERIALS AND FEATURES:



  • Zinc-plated steel body
  • Internal parts in hardened and ground steel
  • BUNA N standard seals
  • Tightness: minor leakage



APPLICATIONS:

Connect P and P' to the 2 pressure flows, ports A and B to the first actuator and ports A' and B' to the second actuator. With lever in position 1, P is connected  to A and P' to A'; with lever in position 2, P is connected to B and P' to B'. Use with lever in central position is not recommended.

Oil temperature: 50°C - Oil viscosity: 30 cSt
