Motosaldatrice ad arco in corrente continua TS 300 SXC EL
    Motosaldatrice ad arco in corrente continua TS 300 SXC EL

TS 300 SXC/EL MOTO-WELDER

Arch welding in direct current. Welding with every type of electrode including cellulosic electrodes. Electronic regulation of welding current. Three-phase and single-phase A.C. current generator. Auxiliary power available even during the welding phase. Differential switch. Lombardini diesel engine. Electric starter. EV motor protection. Towing manual cart. According to EC safety and noise directives. Adjustment range with weld in cc (DC) 20A - 300A. Generation in the AC - 50 Hz three-phase asynchronous alternator, self-excited, self-regulated, brushless. Three-phase power 10 kVA / 400 V / 14.4 A. Single-phase power 5 kVA / 230 V / 2.5 A 21.7 kVA / 110 V / 22.7 A 5 kVA / 48 V / 104 A. Dimensions mm (length x width x height ) without towing dollies: 1320x790x750. Dry weight kg (without towing dollies): 375. Welding process: TIG and electrode. Max welding current: 300A.

Information request

Technical Data

Description Max welding electricity Dimensioni without towing trolley L x w x h mm Weight kg (without towing trolley) Welding process
Z-MOTOSALDATRICE TS 300 SXC/EL 300 A 1320x790x750 375 elettrodo e TIG a striscio

Description

Arch welding in direct current. Welding with every type of electrode including cellulosic electrodes. Electronic regulation of welding current. Three-phase and single-phase A.C. current generator. Auxiliary power available even during the welding phase. Differential switch. Lombardini diesel engine. Electric starter. EV motor protection. Towing manual cart. According to EC safety and noise directives. Adjustment range with weld in cc (DC) 20A - 300A. Generation in the AC - 50 Hz three-phase asynchronous alternator, self-excited, self-regulated, brushless. Three-phase power 10 kVA / 400 V / 14.4 A. Single-phase power 5 kVA / 230 V / 2.5 A 21.7 kVA / 110 V / 22.7 A 5 kVA / 48 V / 104 A. Dimensions mm (length x width x height ) without towing dollies: 1320x790x750. Dry weight kg (without towing dollies): 375. Welding process: TIG and electrode. Max welding current: 300A.

Application Sectors
